Product series
ECONOMIC
Standard price from:
On request
MATERIALS:
white polycarbonate body;
transparent oropal polycarbonate cover;
MOUNTING:
escape luminaire –surface on the wall or on the ceiling;
exit sign –surface on the wall;
POWER SUPPLY:
230 VAC±10%/ 50-60 Hz;
LIGHT SOURCE:
1W LED;110lm;
VIEWING DISTANCE:
20m;
CHARGING:
max 24h;
AUTONOMY & BATTERIES:
1h or 3h; Ni-Cd;
INSULATION CLASS:
II
IP RATING:
IP65
AMBIENT TEMPERATURE:
ta: 0°C –40°C
OPTIONS:
PT -manual test button;
ADDITIONAL INFO:
network power supply and battery charge LED indicator;
deep discharge protection;
