MODUS DON R
Linear LED luminaire for continuous light lines
Standard price from:
DON…/R is a high-efficiency linear LED luminaire designed for continuous light line systems. The construction allows the creation of long, visually consistent lighting lines.
The housing consists of a powder-coated aluminum profile with metal end caps, ensuring mechanical durability and efficient heat dissipation.
The luminaire achieves efficacy up to 148 lm/W and low glare with UGR < 16, making it suitable for offices and public interiors.
Mechanical connection is ensured by an integrated locking system, while electrical connection is provided via plug-in connectors.
Applications include offices, open-plan spaces, schools, retail, and representative interiors.
| Mounting method: | Suspended | Protection class: | I | With movement sensor: | Yes | Type of control gear: | LED operating device current-controlled | Color rendering index CRI: | 80-89 | Light source type: | LED | Anti-glare limiting UGR: | 16 | Color temperature controllable (K): | Yes | Suitable for light line configuration: | Yes | Light outlet: | Direct | Light sharing: | Symmetric | Nominal voltage (V): | 220...240 |
| Degree of protection (IP): | IP20 | Color temperature (K): | 4000, 6500, 3000, 2700, 5700, 2700...6500 | Rated lifetime L70/B50 (h): | 100000 | Dimming DALI: | Yes | Dimming manufacturer's proprietary system: | Yes | Product category: | Pendant luminaire | Optical system: | B50 White reflector with lenses 50° C50 Black reflector with lenses 50° C80 Black reflector with lenses 80° B80 White reflector with lenses 80° CM80 Black MAT reflector with lenses 80° BM80 White MAT reflector with lenses 80° CM50 Black MAT reflector with lenses 50° BM50 White MAT reflector with lenses 50° | Made in Czech republic: | Yes | Replaceability: | Replaceable light source by professional, replaceable ballast Replaceable light source by professional, replaceable ballast | Photobiological safety EN 62 471: | RG 0 | MODUS SMART: | Bluetooth Bluetooth |
LoadingProduct page - PDF
