MODUS MEGA LED 1220mm,wide beam, 2x LED , 840, PC cover, pendant, 600 mA no dimmable, with gear box

Metal industrial luminaire with IP65 - eco

Code: MEGALW2M4PCV4/600ND
EAN: 8596099061524

Luminaire properties

Product category:High bay luminaireEffective luminous flux (lm):13000
System power (W):87Luminaire efficacy (lm/W):149
Rated lifetime L70/B50 (h):100000Rated lifetime L80/B50 (h):80000
Degree of protection (IP):IP65Mounting method:Pendant
Color housing:White
Impact strength:IK10
Material housing:SteelLight source included:Yes
Fire resistance D:YesRated ambient temperature (°C):-25...+45
Made in Czech republic:Yes

Light source

Light source type:LEDColor temperature (K):4000
Color rendering index CRI:80-89Replaceability:Removeable light source, replaceable ballast

Optical system

Optical system:PCReflector:High-gloss
Light sharing:SymmetricMaterial reflector:Aluminium

Dimensions

Length (mm):1224Width (mm):197
Height/depth (mm):90Size version:M
Weight (kg):8

Electrical values

Protection class:IVoltage type:AC
Type of control gear:LED operating device current-controlledNominal voltage (V):220...240
Control gear included:YesNo dim function:Yes
LoadingLoading

Filters

Effective luminous flux (lm)

10500
27000

System power (W)

87
173
Product name
MEGAL2M4KNV4/600ND
Effective luminous flux (lm): 12000
System power (W): 87
Color temperature (K): 4000
Optical system: KN
Length (mm): 1224
MEGAL2M4PCNV4/600DALI
Effective luminous flux (lm): 10500
System power (W): 87
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL2M4PCNV4/600ND
Effective luminous flux (lm): 10500
System power (W): 87
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL2M4V4/600ND
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGAL4M4KNV4/1200ND
Effective luminous flux (lm): 24000
System power (W): 173
Color temperature (K): 4000
Optical system: KN
Length (mm): 1224
MEGAL4M4PCNV4/1200DALI
Effective luminous flux (lm): 21000
System power (W): 173
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL4M4PCNV4/1200ND
Effective luminous flux (lm): 21000
System power (W): 173
Color temperature (K): 4000
Optical system: PCN
Length (mm): 1224
Ball-proof: Yes
MEGAL4M4V4/1200DALI
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGAL4M4V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGAL4M5V4/1200DALI
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
MEGAL4M5V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
MEGALW2M4PCOV4/600ND
Effective luminous flux (lm): 10800
System power (W): 87
Color temperature (K): 4000
Optical system: PCO
Length (mm): 1224
MEGALW2M4PCV4/600DALI
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 4000
Optical system: PC
Length (mm): 1224
MEGALW2M4PCV4/600ND
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 4000
Optical system: PC
Length (mm): 1224
MEGALW2M4V4/600DALI
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW2M4V4/600ND
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW2M4V4/600ND/90
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW2M5PCOV4/600ND
Effective luminous flux (lm): 10800
System power (W): 87
Color temperature (K): 5700
Optical system: PCO
Length (mm): 1224
MEGALW2M5PCV4/600DALI
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 5700
Optical system: PC
Length (mm): 1224
MEGALW2M5PCV4/600ND
Effective luminous flux (lm): 13000
System power (W): 87
Color temperature (K): 5700
Optical system: PC
Length (mm): 1224
MEGALW2M5V4/600ND
Effective luminous flux (lm): 13500
System power (W): 87
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
MEGALW4M4PCOV4/1200DALI
Effective luminous flux (lm): 21500
System power (W): 173
Color temperature (K): 4000
Optical system: PCO
Length (mm): 1224
MEGALW4M4PCOV4/1200ND
Effective luminous flux (lm): 21500
System power (W): 173
Color temperature (K): 4000
Optical system: PCO
Length (mm): 1224
MEGALW4M4PCV4/1200ND
Effective luminous flux (lm): 26200
System power (W): 173
Color temperature (K): 4000
Optical system: PC
Length (mm): 1224
MEGALW4M4V4/1200DALI
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW4M4V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 4000
Optical system: C
Length (mm): 1224
MEGALW4M5PCV4/1200ND
Effective luminous flux (lm): 26200
System power (W): 173
Color temperature (K): 5700
Optical system: PC
Length (mm): 1224
MEGALW4M5V4/1200ND
Effective luminous flux (lm): 27000
System power (W): 173
Color temperature (K): 5700
Optical system: C
Length (mm): 1224
